    Super Low Insertion Loss MTP Trunk Cable 8 Cores Trunk Cable Yellow Color

    Ask Lasest Price
    Brand Name : OMC or OEM
    Model Number : MTP-SC
    Certification : ROHS and ISO
    Price : Negotiation
    Supply Ability : 1000/pcs/month
    Delivery Time : 5 - 8 work days
    • Product Details
    • Company Profile

    Super Low Insertion Loss MTP Trunk Cable 8 Cores Trunk Cable Yellow Color

    Super Low Insertion Loss MTP Trunk Cable 8 Cores Trunk Cable Yellow Color


    MTP-SC harness cables provide a transition from multi-fiber cables to individual fibers or duplex connectors. Known as MTP breakout cable or MTP fan-out cable as well, it has a single MPO connector on one end that breaks out into 4-12 connectors, and these connector types can be LC, SC, ST, etc. It’s available in 4, 6, 8, or 12 fiber cable configurations with lengths from 0.5-100 meters and other customized lengths. MTP harness cable provides a reliable, cost-effective cabling system for migrating from legacy 10G to higher speed 40G/100G Ethernet. The following are the advantages of MTP harness cable:

    • Space saving—The active equipment and backbone cable are good for saving space.
    • Easy deployment—Factory terminated system saves installation and network reconfiguration time.
    • Reliability—High standard components are used in the manufacturing process to guarantee the product qualit

    MTP-SC Fiber Patch Cord are terminated with MTP and SC connector on both end. All of OMC’s MTP Connectors are from USCONEC.


    MTP products’ Standard:

    • Meets IEC Standard IEC-61754-7; JIS C5982; TIA-604-5(FOCIS5); Telcordia GR-1435-CORE compliant
    • Structured cabling per TIA-568-C

    Other connectors’ Industrial Standard:


    SC: TIA/EIA, FOCIS3, GR-326.NTT-SC IEC61754-4 and JIS C5973.


    MTP-SC 8F harness cable's Specification:


    Connector AMTP Female (pinless)Connector BSC UPC
    Fiber ModeOM3 50/125μmWavelength850/1300nm
    MTP Connector IL0.35dB Max(0.15dB Typ.)SC Connector IL≤0.2dB
    MTP Connector RL≥20dBSC Connector RL≥20dB
    Attenuation at 850nm≤2.3dB/kmAttenuation at 1300nm≤0.6dB/km
    Jacket OD3.0mmFan-Out Diameter2.0mm
    Installation Tensile Load100 NLong-Term Tensile Load50 N
    Storage Temperature-40°C to +85°COperating Temperature-10°C to +70°C
    Cable JacketLSZHFiber Count8 Fibers

    Products detail:


    MTP Trunk Cable


    Cable Drawing(LC for reference)


    MTP Trunk Cable OM3 MTP Female to 4 SC UPC Duplex 8 Fibers 50 / 125 harness Breakout Patch Cable 1

    MTP Trunk Cable OM3 MTP Female to 4 SC UPC Duplex 8 Fibers 50 / 125 harness Breakout Patch Cable 2


    Application:


    MTP Trunk Cable OM3 MTP Female to 4 SC UPC Duplex 8 Fibers 50 / 125 harness Breakout Patch Cable 3


    Features:

    - Low insertion loss, high return loss
    - MT based Multi-fiber Connector, 4,8,12 and 24 fiber connector terminations and assemblies
    - Economical solution for mass-termination of fiber
    - Designed for low loss and standard loss SM and MM applications
    - Ruggedized round cable, oval cable and bare ribbon options available
    - Color coded housings available to differentiate fiber type, polish type and/or connector grade
    - Good in repeatability and exchangeability

    AVAILABILITY:

    - Ribbon and bundle cable available;
    - Patch cord, pigtail cable assemblies available.
    - MT-MT ribbon patch cord is available.
    - MPO Loopback available



    Company Information:


    OMC industry co., limited, which was founded by an expert team, has been exporting FTTX passive products since 2007. We focus on providing innovative and integrated FTTX solutions for a variety of applications/Networks. Our capabilities include product/solution design, development, enhancement and integration. Our products are among the highest performing in the industry and truly represent the best values in the industry. We also offer training, pre and post-sales support. We help you select the right products for your Optical network's needs.


    MTP Trunk Cable OM3 MTP Female to 4 SC UPC Duplex 8 Fibers 50 / 125 harness Breakout Patch Cable 6

    MTP Trunk Cable OM3 MTP Female to 4 SC UPC Duplex 8 Fibers 50 / 125 harness Breakout Patch Cable 7

    MTP Trunk Cable OM3 MTP Female to 4 SC UPC Duplex 8 Fibers 50 / 125 harness Breakout Patch Cable 8

    MTP Trunk Cable OM3 MTP Female to 4 SC UPC Duplex 8 Fibers 50 / 125 harness Breakout Patch Cable 9

    MTP Trunk Cable OM3 MTP Female to 4 SC UPC Duplex 8 Fibers 50 / 125 harness Breakout Patch Cable 11

    MTP Trunk Cable OM3 MTP Female to 4 SC UPC Duplex 8 Fibers 50 / 125 harness Breakout Patch Cable 12


    FAQ:


    1. Are you the real factory?

    Yes,we are the real factory more than 10 years


    2. What is your main products?

    Outdoor fiber optic cables; indoor fiber optic cables;FTTH Drop cables;

    Indoor armored patch cords fiber cable; Optical patch cords SC/LC/FC/ST; MTP/MPO optical patch cord.


    3. Do you have certificate for raw material?

    We build long-term relationship cooperation with qualified ISO9001, ROHS raw material suppliers.


    4. What is your delivery time?

    Within 24 hours for normal kinds of fiber optic cable;

    3~5 days for fiber optic patch cords with 10000 connectors.


    5. MOQ: what is your minimum quantity?

    MOQ for fiber optic cables: 1KM

    There is no MOQ required for fiber optic patch cords,as there’s stock for normal kinds.


    6. Do you have distributor in other country or domestic?

    Until now, we sell our products to customers directly. And factory price could be offered.


    7. Payment

    For large order

    For small orders: T/T,Western Union and Paypal are acceptable
